ND-VFC250TB Best Quad Seal Bag Packaging Machine:Proven Granule Solution

ND-VFC250TB

If you are looking for the Best Quad Seal Bag Packaging Machine, our proven granule solution is engineered to deliver high-speed, professional results. This advanced Quad Seal Bag Packaging Machine is specifically designed for the precision handling of granule products, ensuring every bag features the sharp, four-corner seal that premium brands demand for maximum shelf impact.

Packing Speed: 20-40bags/min
bag size: L:80-400mm W:80-200mm
Dimensions: 1493x2049x2179mm
ND-C80E Interactive Features Module

Feature Of Quad Seal Bag Packaging Machine

  • 1 The quad seal bag is more attractive to consumers than other ordinary packaging bags, with an outstanding appearance that can stimulate consumers’ desire to buy.
  • 2 This machine has a beautiful appearance, transparent and clear safety door, which improves the overall style of the packaging machine. It not only allows users to see the internal structure, but also more convenient to operate.
  • 3 Adopt 6 independent temperature control systems to control the temperature of 4 vertical seals and 2 horizontal seals respectively. The temperature can be set according to different packaging materials to ensure the beautiful and firm sealing of the bag.
  • 4 Electrical components adopt French Schneider or Japanese Mitsubishi, including PLC, relay and touch screen, etc. The independent temperature control system adopts Omron (Japan Omron), and the pneumatic control system adopts SMC (Japan).
  • 5 Low failure rate, high efficiency and stability, safe production for more than 15 years.
  • 6 The machine structure is convenient for maintenance and cleaning.

VFC250TB is suitable for quad seal bag, with a beautiful appearance and more attractive to consumers. Widely used in the coffee beans coffee powder,snack food , pet food , biscuits and other products.

Technical Parameters Of Quad Seal Bag Packaging Machine

Parameter Specification
Packing Speed 20-40 bags/min
bag size: L:80-400mm W:80-200mm
Air consumption 0.3m³/min
Air Pressure ≥0.6Mpa
Total Power 220V/380V,50-60Hz, 5.5Kw
Weight 800Kg
Dimensions 1493x2049x2179mm

Bag Type Of Quad Seal Bag Packaging Machine

    Inner bag: Quad seal bag,quad seal bag with one way exhaust valve.

    Packaging Materials: Aluminized film, paper-plastic composite film and other laminated film.

Applications Of Quad Seal Bag Packaging Machine

Granules: Coffee beans ,snacks, cereals, nuts,cookies,wafer biscuit,loose tea leaf, frozen food, candy, seeds,veterinary medicine, pet food etc.

Powder: Coffee powder,milk powder, flour, grain powder, starch, seasoning powder, protein powder, vegetable powder, fruit powder, medicine powder etc.

Machine Operation Demonstration

FAQ Of Quad Seal Bag Packaging Machine

How to solve the film deviation?
1、The position of the roll film can be quickly corrected by the correction device on the touch screen.
2、Check whether the position of the center line of the film roll on the air shaft is in a straight line with the center line of the former.
3、More solution you can contact us for assistant.

How to solve the bag sealing?
1、Properly extend the horizontal sealing delay in the parameter setting.
2、Properly increase the temperature of the corresponding temperature control table.
3、Check whether the material is clamped, and adjust the blanking time through the parameter setting.

ND-VFC250TBG is a fully automatic vertical packaging machine designed for roasted coffee beans. Compatible with roll film for high-volume production, it supports vent valve installation to preserve freshness and extend storage duration. The integrated electronic weighing system ensures precise weight measurement for each package.

Media Of Quad Seal Bag Packaging Machine

ND-VFC250TB Quad Seal Bag Packaging Machine

VFC250TB is suitable for quad seal bag, with a beautiful appearance and more attractive to consumers. Widely used in the coffee beans coffee powder,snack food , pet food , biscuits and other products.

Especially with the addition of the one way exhaust valve function, the quad seal bag type has become the preferred bag type for packaging coffee beans and coffee powder.
