ND-C80E Product Main Section with Carousel

NPA-360 25-50kg Powder Automatic Bagging Machine

NPA-360

Model NPA-360 bagging machine is an high speed automatic bagging machine for 25-50kg powder quantitative packing, with automatic weighting,filling , bagging, and sealing system. It can be equipped with detecting equipment and robot palletizing system, realize intelligent，integrated， high efficiency，full automatic production.

Max Speed: 360 bph
Min Size: 800mm*500mm(Other sizes can be customized)
Max Size: 1000mm*600mm(Other sizes can be customized)
ND-C80E Interactive Features Module

Feature Of 25-50kg Powder Automatic Bagging Machine

  • 1 The process of weighing, bag loading, bag opening, material discharging and bag sewing is fully automated.
  • 2 Suitable for laminated woven , non laminated woven (with PE liner inside), kraft paper (with PE liner inside), PE, flat or gusseted open mouth bags.
  • 3 Adopting horizontal double screw feeding, with bucket metering, fast weighing speed and high precision.
  • 4 Extraction device is optional at the lower material mouth, which can effectively reduce the air content in the material.
  • 5 Bag holding mechanism is equipped with exhaust device, effectively discharging the bag mouth gas.
  • 6 The packing machine is equipped with dust removal ports in many places to avoid raising dust.
  • 7 With automatic fault alarm function, according to the fault prompt can be quickly eliminated.
  • 8 Customize the 25kg-50kg packaging line according your factory scene and individual requirements.
  • 9 It can equip with other related machines ,like metal checker, weight checker,labeling , palletizing,finished pallet wrapping machine and so on.When the packaging line running no need worker at the scene, save cost to the greatest extent.

If you want to make the packaging line fully fit the actual factory layout and personalized needs, allowing customers to avoid adjusting workshop plans to adapt to equipment, choosing the customized 25-50kg packaging line service of the NPA-360 is the best option.

Technical Parameters Of 25-50kg Powder Automatic Bagging Machine

Parameter Specification
Model NPA-360
Packing weight 25kg-50kg
Packing speed 180-360bags/hour
Weighting accuracy ± 0.1%~0.2%
Bag size 800mm-1000mm(L)×500mm-600mm(W)(Other sizes can be customized)
Environment temperature 0~40℃
Voltage power/ Frequency AC380V 50Hz，14KW
Air requirement 0.4-0.7MPa，40Nm³/h
Machine dimension 7553×4142×4870(L*W*H,mm)

Bag Type Of 25-50kg Powder Automatic Bagging Machine

    Bag type: Suitable for laminated woven , non laminated woven (with PE liner inside), kraft paper (with PE liner inside), PE, flat or gusseted open mouth bags.

Applications Of 25-50kg Powder Automatic Bagging Machine

Model NPA-360 Suitable for quantitative packing 25-50kg of flake or powder materials in food, food addtives, pharmaceuticals ,chemical and other industries.

Machine Operation Demonstration

FAQ Of 25-50kg Powder Automatic Bagging Machine

The suction cup of the bagging machine can’t suck the bag.
The suction cup is cracked Solution 1: Replace in time

The bag opening mechanism of the bagging machine does not move.
Photoelectric did not catch the reflector Solution: Clean up photoelectric dust.

The bag of the nip shaping machine tilts forward or backward during transportation.
The speed of the conveyor belt is not synchronized with the stand-up bag conveyor Solution: Adjust the frequency converter of the nip shaping machine.

The belt of the jaw shaping machine falls off or is loose.
The conveyor belt is stretched Solution: Adjust the belt tension of the driven belt wheel to a proper degree.

If you want to make the packaging line fully fit the actual factory layout and personalized needs, allowing customers to avoid adjusting workshop plans to adapt to equipment, choosing the customized 25-50kg packaging line service of the NPA-360 is the best option.

Media Of 25-50kg Powder Automatic Bagging Machine

NPA-360 25-50kg Powder Automatic Bagging Machine

Model NPA-360 bagging machine is an high speed automatic bagging machine for 25-50kg powder quantitative packing, with automatic weighting,filling , bagging, and sealing system. It can be equipped with detecting equipment and robot palletizing system, realize intelligent，integrated， high efficiency，full automatic production.

NPA-360 ...
